Product Details
Place of Origin: China
Brand Name: SXEGL
Certification: CE/EPA/FCC/ROSH/ISO
Model Number: EG25
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 100-700
Packaging Details: Carton and foam
Delivery Time: 5-14
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: Worldwide delivery
|
Screw Grade:
|
C7 Rolling 1205/1210(Slenderness Ratio 1:52.5)
|
Repeatable Positioning Accuracy(mm):
|
±0.02
|
Max Radial Load As A Barrier Cylinder(KG):
|
75
|
Standard Motor Output (W) 50W Stepper 28 Rated Torque(Nm) 0.16 0.09 Screw Grade C7 Rolling 0802(Sl:
|
30.50.100
|
Piston Rod Rotation Angle:
|
±0.7 Degree
|
The Body Weight Of Omm Stroke(KG):
|
2.1
|
|
Screw Grade:
|
C7 Rolling 1205/1210(Slenderness Ratio 1:52.5)
|
|
Repeatable Positioning Accuracy(mm):
|
±0.02
|
|
Max Radial Load As A Barrier Cylinder(KG):
|
75
|
|
Standard Motor Output (W) 50W Stepper 28 Rated Torque(Nm) 0.16 0.09 Screw Grade C7 Rolling 0802(Sl:
|
30.50.100
|
|
Piston Rod Rotation Angle:
|
±0.7 Degree
|
|
The Body Weight Of Omm Stroke(KG):
|
2.1
|
| Parameter | Value |
|---|---|
| Standard Motor Output | 100W / Stepper 42 |
| Rated Torque | 0.32Nm / 0.25Nm |
| Screw Grade | C7 Rolling 1205/1210 (Slenderness ratio 1:52.5) |
| Repeatable Positioning Accuracy | ±0.02mm |
| Max Thrust | 170-340N (1210), 125-250N (1205) |
| Max Speed | 50-500mm/s |
| Stroke | 30/50/100mm |
| Max Load | 20kg (Horizontal), 24kg (Vertical) |
| Max Radial Load | 75kg |
| Piston Rod Rotation Angle | ±0.7° |
| Weight (0mm stroke) | 2.1kg |
| Weight Added per 10mm | 0.2kg |
| Magnetic Switch Options | Contact reed (1m), NPN/PNP transistor (3m) |
| Model | EG16 | EG20 | EG25 | EG32 | EG40 |
|---|---|---|---|---|---|
| Max Thrust (N) | 88-220 | 88-400 | 125-340 | 150-1280 | 150-1280 |
| Max Speed (mm/s) | 40-100 | 40-250 | 50-500 | 100-500 | 100-500 |
| Max Load (kg) | 5 | 8 | 20/24 | 45/27 | 60/27 |
| Radial Load (kg) | - | - | 75 | 100 | 150 |
