High Precision Guide Rod Cylinder Grey Guided Cylinder 30mm 50mm 100mm Stroke

Product Details

Place of Origin: China

Brand Name: SXEGL

Certification: CE/FCC/EPA/ROSH/ISO

Model Number: EG

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $142-$2999

Packaging Details: Carton

Delivery Time: Small orders usually takes 3-7 days,big order usually 20-35 days, depending on orders quantity and whether are standard size.

Payment Terms: Visa /Mastercard/PayPal/Apple Pay/Google Pay

Supply Ability: All products have passed CE certification and comply with EU RoHS environmental standards

Get Best Price

Chat Now

Product Details

Product Description

Highlight:
                                                                                                                                    High Precision Guide Rod Cylinder, Guide Rod Cylinder Grey, Guided Cylinder 30mm Stroke


Product Name:	Guide Rod Cylinder	Color:	Grey
Stroke:	30mm 50mm 100mm	Max Load:	5KG

Product Name:	Guide Rod Cylinder
Color:	Grey
Stroke:	30mm 50mm 100mm
Max Load:	5KG

High Precision Guide Rod Cylinder Grey Guided Cylinder 30mm 50mm 100mm Stroke

High Precision Energy Efficient Electric Cylinders Eco Friendly Low Maintenance

SEXGL High-Precision Electric Cylinders deliver unparalleled motion control for sustainable industrial operations, trusted by BYD (EV battery assembly) and BOE (cleanroom robotics) across North America, Europe, Southeast Asia, and South America. Engineered to replace hydraulic/pneumatic systems, our electric cylinders combine precision positioning with reduced environmental impact, aligning with global carbon-neutral initiatives.

Model	Stroke	Lead	Motor installation	Motor brand	Motor power	Magnetic reed switch
EG16	50mm	P02	D: Direct installation	S: Stepper	28	S1
	30mm		P: Indirect installation		S3: Switch*3
	50mm				Sn: Switch*n
	100mm

Technical Parameters

Standard motor output (W) Stepper 28

Rated torque (Nm) 0.09

Screw grade C7 Rolling 0802 (Slenderness ratio 1:50)

Repeatable positioning accuracy (mm) ±0.02

Screw specification 802 / 805

Max thrust (N) 220 / 88

Max speed (mm/s) 40 / 100

Stroke (mm) 30 / 50 / 100

Max load (KG) Horizontal: 5 / Vertical: 5

Piston rod rotation angle ±0.7 degree

Body weight of 0mm stroke (KG) 1.2

Weight added per 10mm (KG) 0.09

Component weight of direct installation motor (KG) 0.08

Component weight of indirect installation motor (KG) 0.15

Magnetic Switch Options

CS1-H-1M: Contact type reed switch, wire length 1m
CS1-HN-3M: Contactless transistor NPN type, wire length 3m
CS1-HP-3M: Contactless transistor PNP type, wire length 3m
