Product Details
Place of Origin: CHINA
Brand Name: SXEGL
Certification: CE/FCC/EPA/ROSH/ISO
Model Number: MK85
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 300-1000
Packaging Details: Carton and foam
Delivery Time: 5-45
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: Worldwide delivery
|
Repeatable Positioning Accuracy(mm):
|
±0.1
|
Rated Thrust(N):
|
340
|
Standard Stroke(mm)*3:
|
100-6000mm/100mm Interval
|
AC Servo Motor Capacity(W):
|
750
|
Belt Width(mm):
|
46
|
High Rigidity Linear Slide(mm):
|
W20XH15
|
|
Repeatable Positioning Accuracy(mm):
|
±0.1
|
|
Rated Thrust(N):
|
340
|
|
Standard Stroke(mm)*3:
|
100-6000mm/100mm Interval
|
|
AC Servo Motor Capacity(W):
|
750
|
|
Belt Width(mm):
|
46
|
|
High Rigidity Linear Slide(mm):
|
W20XH15
|
| ※ Basic specifications MK85 | ||||||
| Specification | Motor speed(rpm/min) | 5:1 | 7:1 | 10:1 | ||
| Max speed(mm/s)*1 | 2000 | 1428 | 1000 | |||
| Max load(kg) | Horizontal | 40 | 60 | 100 | ||
| Vertical*2 | 14 | 21 | 24 | |||
| Repeatable positioning accuracy(mm) | ±0.1 | |||||
| Rated thrust(N) | 340 | |||||
| Standard stroke(mm)*3 | 100-6000mm/100 interval | |||||
| Component | AC servo motor capacity(W) | 750 | ||||
| Belt width (mm) | 46 | |||||
| High rigidity linear slide(mm) | W20XH15 | |||||
| Origin sensor | Plug | PM-T45(NPN) | ||||
| Model | Motor speed (rpm/min) | Max speed (mm/s) | Max load (kg) | Repeatable positioning accuracy (mm) | Rated thrust (N) | Standard stroke (mm) | AC servo motor capacity (W) | Belt width (mm) | High rigidity linear slide (mm) | Origin sensor |
|---|---|---|---|---|---|---|---|---|---|---|
| MK65 | 3:1 | 1833 | 30 (H) 9 (V) |
±0.1 | 220 | 100-6000mm /100mm interval | 400 | 32 | W15XH12.5 | PM-T45(NPN) |
| 5:1 | 1100 | 45 (H) 15 (V) |
||||||||
| 7:1 | 785 | 55 (H) 16 (V) |
||||||||
| 10:1 | 550 | 60 (H) 17 (V) |
||||||||
| MK85 | 5:1 | 2000 | 40 (H) 14 (V) |
±0.1 | 340 | 100-6000mm /100 interval | 750 | 46 | W20XH15 | PM-T45(NPN) |
| 7:1 | 1428 | 60 (H) 21 (V) |
||||||||
| 10:1 | 1000 | 100 (H) 24 (V) |
||||||||
| MK110 | 10:1 | 1250 | 100 (H) 23 (V) |
±0.1 | 765 | 100-6000mm /100 interval | 750 | 50 | W23XH18 | PM-T45(NPN) |
| 15:1 | 833 | 150 (H) 36 (V) |
||||||||
| 20:1 | 625 | 200 (H) 50 (V) |
